ENSEMBLE DX | DJI Inspire 1

Although the DJI Inspire 1 is an older model, it remains an attractive solution for those who want to experience the features of a professional drone at an affordable cost. This set is ideal for beginners or users looking for a simple and functional device for basic aerial photography or videography needs.

Device

Model : T600 Weight :

• 6.27 lbs (2845 g, including propellers and battery, without gimbal or camera)
• 6.74 lbs (3060 g, including propellers, battery and Zenmuse X3)

GPS positioning accuracy :

• Vertical: ±0.5 m
• Horizontal : ±2.5 m

Maximum angular velocity :

• Pitch : 300°/s
• Speed: 150°/s

Maximum pitch angle: 35° Maximum climb speed: 5 m/s (16.4 ft/s) Maximum descent speed: 4 m/s (13.1 ft/s) Maximum speed: 79 km/h (49 mph, ATTI mode, no wind) Maximum takeoff altitude :

• 2500 m (1,55 mi)
• 4,500 m (2.8 mi with special propellers)

Wind resistance: 10 m/s Maximum battery life: Approximately 18 min Motor model: DJI 3510H Propeller model: DJI 1345T Indoor hover: Enabled by default Operating temperature: -10° to 40°C (14° to 104°F) Diagonal distance (excluding propellers): 581 mm (22.8 inches, landing mode) Maximum takeoff weight: 3500 g (7.71 lbs)

Nacelle

Compatible models :

• ZENMUSE X3
• ZENMUSE X5 (optional)
• ZENMUSE X5R (optional)
• ZENMUSE XT (optional)
• ZENMUSE Z3 (optional)

Angular vibration range: ±0.03° Interface type: Detachable Controllable range :

• Pitch: -90° to +30°
• Panoramic: ±320°

Mechanical beach :

• Pitch: -125° to +45°
• Panoramic: ±330°

Maximum controllable speed :

• Pitch : 120°/s
• Panoramic: 180°/s

Remote

Modèle : GL658A Operating frequencies :

• 922.7-927.7 MHz (Japan only)
• 5,725-5,825 GHz
• 2,400-2,483 GHz

Maximum transmission distance (without obstruction, without interference):

• Up to 5 km (FCC)
• Up to 3.5 km (CE)
• Up to 2 km (MIC)

EIRP :

• 10 dBm@900m, 13 dBm@5,8G, 20 dBm@2,4G

Video output ports: USB, mini-HDMI Power supply: Integrated battery Charging: DJI Charger Dual user mode: Master-slave connection Support mobile : Tablette ou smartphone Maximum width of the mobile support: 170 mm

Output power: 9 W Operating temperature: -10° to 40°C (14° to 104°F) Storage temperature :

• Less than 3 months: -20° to 45°C (-4° to 113°F)
• More than 3 months: 22° to 28°C (72° to 82°F)

Charging temperature: 0° to 40°C (32° to 104°F) Batterie : 6000mAh 2S LiPo

Camera

Name : X3 Model: FC350 Total pixels: 12.76 MP Effective pixels: 12.4 MP Maximum image resolution: 4000 x 3000 ISO range :

• Video: 100-3200
• Photo : 100-1600

Electronic shutter speed: 8 s – 1/8000 s Champ de vision (FOV) : 94° CMOS sensor : 1/2,3” Lens: 20mm (35mm equivalent), f/2.8, focus at ∞

Photography Modes :

• Single take
• Rafale : 3/5/7 images
• Auto Exposure Bracketing (AEB): 3/5 frames with 0.7 EV bias
• Time-lapse

Video Modes :

• UHD (4K) : 4096x2160p24/25, 3840x2160p24/25/30
• FHD : 1920x1080p24/25/30/48/50/60
• HD : 1280x720p24/25/30/48/50/60

Maximum throughput: 60 Mbps Supported formats :

• Photo : JPEG, DNG
• Vidéo : MP4/MOV (MPEG-4 AVC/H.264)

Compatible SD cards: Micro SD up to 64 GB, class 10 or UHS-1 required Operating temperature: 0° to 40°C

Battery (Standard and Optional)

Name: Intelligent Flight Battery Model :

• TB47 (Standard) : 4500 mAh
• TB48 (Optional): 5700 mAh

Type : LiPo 6S Energy :

• TB47 : 99,9 Wh
• TB48 : 129,96 Wh

Net weight :

• TB47 : 570 g
• TB48 : 670 g

Operating temperature: -10° to 40°C (14° to 104°F) Storage temperature :

• Less than 3 months: -20° to 45°C (-4° to 113°F)
• More than 3 months: 22° to 28°C (72° to 82°F)

Charging temperature: 0° to 40°C (32° to 104°F) Maximum charging power: 180 W

Lower vision system

Speed ​​range: <8 m/s (at a height of 2 m) Plage d’altitude : 5-500 cm Operating environment: Surfaces with clear patterns and adequate lighting (>15 lux) Operating range: <3 m Ultrasonic sensors operating range: 5-500 cm Ultrasonic sensor environment: Non-absorbent materials and rigid surfaces.

Propellers are not included in this set and will need to be purchased separately.
