DJI Goggles Integra

Combined for convenience

The lightweight DJI Integra Goggles adopt an integrated design that combines a headband and battery into one, eliminating cumbersome cables and allowing you to take the glasses on and off effortlessly.

The built-in battery headband is lightweight, balanced and comfortable to wear.

DJI Goggles Integra can be used while charging and will remain powered for multiple drone flights with a full battery. So you can keep getting high all day long.


HD display

DJI Goggles Integra is equipped with two HD Micro-OLED displays to deliver realistic colors and light and shadow details. The high screen refresh rate presents the fun of flying in a smoother and more fantastic way.

Display technology

Micro-OLED

Screen resolution
Screen resolution

1080p

Maximum brightness
Maximum brightness

700 nits

Maximum screen refresh rate
Maximum screen refresh rate

100Hz [4]

Supported codec formats
Supported codec formats

H.264 and H.265

Ultra-low latency, smooth and stable video transmission


DJI Goggles Integra is equipped with DJI O3 video transmission, providing latency as low as 30ms. The glasses automatically switch between the 2.4GHz and 5.8GHz frequency bands to maintain a stable signal for a smooth, immersive HD viewing experience with minimal interference.

Goggles

• Model

• RCDS13

• Weight

• Approx. 410 g (battery included)

• Dimensions (L×W×H)

• With antennas folded: 170×104×75 mm
  With antennas unfolded: 205×104×104 mm

• Screen Size (single screen)

• 0.49-inch

• Resolution (single screen)

• 1920×1080

• Refresh Rate

• Up to 100 Hz

• IPD Range

• 56-72mm

• FOV (single screen)

• 44°

• Video Recording Format

• MOV

• Supported Video Playback Formats

• MP4, MOV (video formats: H.264, H.265; audio formats: AAC, PCM)

• Operating Temperature

• -10° to 40° C (14° to 104° F)

• Power Input

• Built-in battery

• Supported SD Cards

• microSD (up to 512 GB)

• Recommended microSD Cards

• SanDisk Extreme U3 V30 A1 32GB microSDXC
  SanDisk Extreme Pro U3 V30 A1 32GB microSDXC
  Lexar 1066x U3 V30 A2 64GB microSDXC
  Lexar 1066x U3 V30 A2 128GB microSDXC
  Lexar 1066x U3 V30 A2 256GB microSDXC
  Lexar 1066x U3 V30 A2 512GB microSDXC
  Kingston Canvas Go! Plus U3 V30 A2 64GB microSDXC
  Kingston Canvas Go! Plus U3 V30 A2 128GB microSDXC
  Kingston Canvas React Plus U3 V90 A1 64GB microSDXC
  Kingston Canvas React Plus U3 V90 A1 128GB microSDXC
  Kingston Canvas React Plus U3 V90 A1 256GB microSDXC
  Samsung EVO Plus U3 V30 A2 512GB microSDXC

Video Transmission

• Video Transmission

• When used with different aircraft, the goggles will automatically select the corresponding firmware to match the video transmission specification of the aircraft.
  DJI Avata: O3+

• Operating Frequency

• 2.4000-2.4835 GHz
  5.725-5.850 GHz
  The 5.8 GHz frequency band is currently banned in certain countries or regions. For details, please refer to local laws and regulations.

• Transmitter Power (EIRP)

• 2.4000-2.4835 GHz:
  <30 dBm (FCC)
  <20 dBm (CE/SRRC/MIC/KC)
  5.725-5.850 GHz:
  <30 dBm (FCC)
  <23 dBm (SRRC)
  <14 dBm (CE/KC)

• Transmission Latency

• 1080p/100fps: as low as 30ms
  1080p/60fps: as low as 40ms
  Measured in an open outdoor environment without interference. Actual data varies with different aircraft models.

• Max Transmission Distance

• When used with DJI Avata or the DJI O3 Air Unit, DJI Goggles Integra can achieve the following max video transmission distance:
  10km (FCC), 2km (CE), 6km (SRRC)
  When used with DJI FPV, DJI Goggles Integra can achieve the following max video transmission distance:
  10km (FCC), 6km (CE), 6km (SRRC), 6km (MIC)

• Max Video Bitrate

• 50Mbps
  Measured in an open outdoor environment without interference. Actual data varies with operating environment.

Battery

• Weight

• Approx. 185 g (headband included)

• Dimensions (L×W×H)

• 120×51×71mm

• Capacity

• 2450mAh

• Voltage

• 5.6-8.4V

• Kind

• Li-ion

• Chemical System

• LiNiMnCoO2

• Energy

• 17.64 Wh

• Charging Temperature

• 5° to 45° C (41° to 113° F)

• Max Charging Power

• 15 W (charging when powered off)

• Operating Time

• Approx. 2 hours
  Measured with an ambient temperature of 25° C (77° F), screen brightness at 4, connection to DJI Avata, the video transmission mode set to 1080p/100fps, head tracking off, and the goggles' battery fully charged and not supplying power to external devices such as smartphones.

• DJI Goggles Integra x1
• USB-C OTG Cable x1
• DJI Goggles Integra Eyeglass Frames (Pair) x2
• DJI Goggles Integra Corrective Lenses (Pair) x11
• DJI Goggles Integra Top Headband x1
• Lens Cleaning Cloth x1
